2TF Series Two Stage Screw Air Compressor
2TF series is 2 stage compression fixed speed screw air compressor. The 2-stage compression element is proven to increase efficiency and reliability at large air flow in the harsh conditions, same power but we can give you more compressed air.
Inquiry
Benefits
1. Two stage air end
Much higher efficiency,using same power can provide muchlarger free air delivery.
2. Petoanent magnet
More than 95% high efficiency, that means to have a much better performance than most of the compressors in the market.
3. Centrifugal fan
Lower noise and have a much larger volume than the axial flow fan
4. Separated cold/hot area
Independent cooling channel,high effiency and longer service life
Technical Parameter
| Model | Max Working Pressure | F.A.D | Motor Power | Connection | Net Weight | Dimension (L*W*H) |
|||
|---|---|---|---|---|---|---|---|---|---|
| bar | psig | m3/min | CFM | hp | kw | kgs | mm | ||
| 2TF22-8 | 8 | 116 | 4.1 | 144 | 30 | 22 | Rp1-1/2 | 680 | 1400*880*1350 |
| 2TF22-10 | 10 | 145 | 3.5 | 123 | |||||
| 2TF22-13 | 12.5 | 181 | 3.2 | 113 | |||||
| 2TF30-8 | 8 | 116 | 6 | 212 | 45 | 30 | Rp1-1/2 | 930 | 1950*1100*1390 |
| 2TF30-10 | 10 | 145 | 4.9 | 173 | |||||
| 2TF30-13 | 12.5 | 181 | 4.2 | 148 | |||||
| 2TF37-8 | 8 | 116 | 6.8 | 240 | 50 | 37 | Rp1-1/2 | 930 | 1950*1100*1390 |
| 2TF37-10 | 10 | 145 | 5.8 | 204 | |||||
| 2TF37-13 | 12.5 | 181 | 5.4 | 190 | |||||
| 2TF45-8 | 8 | 116 | 8.2 | 289 | 60 | 45 | Rp1-1/2 | 960 | 1950*1100*1390 |
| 2TF45-10 | 10 | 145 | 7.4 | 261 | |||||
| 2TF45-13 | 12.5 | 181 | 6.6 | 233 | |||||
| 2TF55-8 | 8 | 116 | 11.6 | 409 | 75 | 55 | DN50 | 1870 | 2590*1500*1640 |
| 2TF55-10 | 10 | 145 | 11.3 | 399 | |||||
| 2TF55-13 | 12.5 | 181 | 9 | 318 | |||||
| 2TF75-8 | 8 | 116 | 15.6 | 551 | 100 | 75 | DN50 | 1940 | 2590*1500*1640 |
| 2TF75-10 | 10 | 145 | 11.6 | 409 | |||||
| 2TF75-13 | 12.5 | 181 | 11.3 | 399 | |||||
| 2TF90-8 | 8 | 116 | 18.5 | 653 | 120 | 90 | DN65 | 2170 | 2990*1700*1963 |
| 2TF90-10 | 10 | 145 | 15.2 | 537 | |||||
| 2TF90-13 | 12.5 | 181 | 14.5 | 512 | |||||
| 2TF110-8 | 8 | 116 | 21 | 742 | 150 | 110 | DN65 | 2330 | 2990*1700*1963 |
| 2TF110-10 | 10 | 145 | 18.5 | 653 | |||||
| 2TF110-13 | 12.5 | 181 | 16 | 565 | |||||
| 2TF132-8 | 8 | 116 | 24.7 | 872 | 175 | 132 | DN66 | 2415 | 2990*1700*1963 |
| 2TF132-10 | 10 | 145 | 21.3 | 752 | |||||
| 2TF132-13 | 12.5 | 181 | 18.5 | 653 | |||||
| 2TF160-8 | 8 | 116 | 31 | 1095 | 200 | 160 | DN80 | 3970 | 3450*1880*2120 |
| 2TF160-10 | 10 | 145 | 26 | 918 | |||||
| 2TF160-13 | 12.5 | 181 | 24.7 | 872 | |||||
| 2TF185-8 | 8 | 116 | 35.5 | 1254 | 250 | 185 | DN80 | 4000 | 3450*1880*2120 |
| 2TF185-10 | 10 | 145 | 31 | 1095 | |||||
| 2TF185-13 | 12.5 | 181 | 26 | 918 | |||||
| 2TF200-8 | 8 | 116 | 40 | 1413 | 270 | 200 | DN125 | 5550 | 3820*1980*2210 |
| 2TF200-10 | 10 | 145 | 35.5 | 1254 | |||||
| 2TF200-13 | 12.5 | 181 | 32 | 1130 | |||||
| 2TF220-8 | 8 | 116 | 45 | 1590 | 300 | 220 | DN125 | 5650 | 3820*1980*2210 |
| 2TF220-10 | 10 | 145 | 40 | 1413 | |||||
| 2TF220-13 | 12.5 | 181 | 35.5 | 1254 | |||||
| 2TF250-8 | 8 | 116 | 50 | 1767 | 350 | 250 | DN125 | 5950 | 3820*1980*2210 |
| 2TF250-10 | 10 | 145 | 45 | 1590 | |||||
| 2TF250-13 | 12.5 | 181 | 40 | 1413 | |||||
Video
Download Case
Screw Air compressors are used widely across all industries. Such as automotive, brewing, food packaging, aerospace, construction, and more. Stationary screw compressors are the optimal choice for large industrial applications with a continuous air demand.
