EF Series Mono Phase Screw Air Compressor
EF series is 4in1 mono phase variable speed permanent magnet screw air compressor 4IN1 mean screw air compressor + air tank + air dryer + line air filters are all in 1 This series is most suitable for the auto repair shop, car beauty, etc. It is reliability, energy saving, low noise and small footprint. Give the clean and dry compressed air to protect all your equipment and tools
Inquiry
Benefits
1. Permanent Magnet Motor
Returns to traditional high-efficiency air-end,6 bearings ,morse taper connection to truly integrated host.
2. Anti-emulsification Patent design
Anti-emulsification Patent design,Ensure longer service life of the whole machine.
3. Inverter
Heavy-duty standard inverter,reliable performance,simple to use.
4. After Cooler
Increase the heat dissipationof the cooler ,and the cooling effect is rapid.Technical Parameter
| Model | Max Working Pressure | Capacity | Motor Power | Connection | Dimension (L*W*H) |
Air Tank | ||
|---|---|---|---|---|---|---|---|---|
| -- | bar | psig | L/min | hp | kw | inch | mm | L |
| C5E | 8 | 116 | 200-400 | 5 | 3.7 | G1/2 | 1020*540*1035 | 130L |
| 10 | 145 | 175-350 | ||||||
| 12.5 | 182 | 150-300 | ||||||
| C6E | 8 | 116 | 250-500 | 6 | 4.5 | G1/2 | 1020*540*1035 | 130L |
| 10 | 145 | 210-420 | ||||||
| 12.5 | 182 | 180-360 | ||||||
| C7E | 8 | 116 | 315-630 | 7 | 5.5 | G1/2 | 1020*540*1035 | 130L |
| 10 | 145 | 275-550 | ||||||
| 12.5 | 182 | 210-420 | ||||||
| C10E | 8 | 116 | 490-980 | 10 | 7.5 | G1/2 | 1060*560*1270 | 220L |
| 10 | 145 | 450-900 | ||||||
| 12.5 | 182 | 400-800 | ||||||
Video
Download Case
Screw Air compressors are used widely across all industries. Such as automotive, brewing, food packaging, aerospace, construction, and more. Stationary screw compressors are the optimal choice for large industrial applications with a continuous air demand.
